H&R TRAK+® Wheel Spacers Audi A6 e-tron Sportback (GHA) / A6 e-tron Avant (GH5)

Description

H&R TRAK+® Wheel Spacers for the Audi A6 e-tron Sportback (GHA), Audi A6 e-tron Avant (GH5).

H&R lists part number B469566450 against 6 vehicle variants (engine and build-date combinations). Please match your engine and build date to the compatibility list below before ordering; we also check your registration or VIN before dispatch.

Features

• Approval: Part Type Approval (PTA)
• Thread size: M14x1,5
• Number of holes: 5

Notes from H&R

Please note additional information and vehicle-specific technical notes!

DR = The wheel spacer should be fitted between the wheel and the axial hub using longer bolts not supplied - please order separately. When ordering the longer bolts please state which cone type you require (i.e. taper, round, loose round or flat) and the required extra length. All screws for the DR systems have to be orderded separately.

All DR-Systems require longer wheel-bolts. These have to be ordered separately. When ordering wheel-bolts please follow these guidelines: If possible name the type of the wheel when ordering. New bolts must be longer than the original ones by half of the total Track-widening. For example: With a 30 mm DR-kit you will require bolts that are 15 mm longer than the original bolts. The bold-head must be identical to the existing bolt: Taper 60° Round-head for M12/d24 mm, for M14/d28 mm Round-head for M12/d26 mm (e.g. OE VAG-wheels) Flat-head with disc for CITROEN/PEUGEOT-vehicles M12x1,25 Flat-head for PORSCHE-original-wheels M14x1,5 Safety Guidelines (No. of turns for wheel screws) M12x1,5 = 6,5 turns = approx. 10 mm of load bearing shaft length M12x1,25 = 8,0 turns = approx. 10 mm of load bearing shaft length M12x1,75 = 6,5 turns = approx. 12 mm of load bearing shaft length M14x1,5 = 7,5 turns = approx. 12 mm of load bearing shaft length 1/2"UNF = 8,0 turns = approx. 11 mm of load bearing shaft length Please ensure that the wheel screws do not damage any part of the brake system (ABS sensors etc.) Turn the wheel first by hand and check clearance on the inside (max. tolerance for some vehicles is only 2 mm (RA Mercedes).

Note 56: The wheel spacers with type approval (TTG) are only permitted for the original wheels specified in the TTG for the wheel spacers. Approval is required when using certain wheel/tire combinations. Approvals and requirements can be found in the TTG.

Documents

• Installation manual
• Installation manual 2
• Product information
• Service information
• Part type approval (PTA)

Compatibility

• Audi A6 e-tron Sportback (GHA) (07/2024-): Performance (280kW, 0 cc, 0 cyl.); 83 (240kW, 0 cc, 0 cyl.); 100 quattro (340kW, 0 cc, 0 cyl.)
• Audi A6 e-tron Avant (GH5) (07/2024-): Performance (280kW, 0 cc, 0 cyl.); 83 (240kW, 0 cc, 0 cyl.); 100 quattro (340kW, 0 cc, 0 cyl.)

Compatibility Check

To ensure the part(s) you have ordered fits your vehicle, we run a compatibility check prior to dispatch. We can do this either using your registration number (UK) or the last 7 digits of your VIN. Simply enter your car details prior to checkout.

Part Number

B469566450

More Information

Manufactured by

H&R

EAN

4048419342201
